技术参数 Technical specifications
|
【型号/Model：SS-JZX645】 |
控制电压 Control voltage |
AC 380V/50HZ DC 24V (可选/ as agreed) |
|
|
适用于操作ISO标准20’,40’,45’和两个20’集装箱 For operation with ISO standard 20’,40’, 45’ and twin 20’ containers |
总功率 Total power |
~8KW |
|
|
额定起重量 (同心/单箱) SWL (Concentric/ Single mode) |
40T |
防护等级 Precaution class |
IP 55 |
|
额定起重量 （偏心/双箱） SWL (Eccentricity / Twin 20’ mode) |
65T |
系统工作压力 Operating pressure of the system |
120bar |
|
四角吊耳负重 Load of lifting lugs at four corner |
19.5t×4 |
环境温度 Ambient temperature |
-20℃ ~+55℃ |
|
自重(吊具部分) Self-weight (spreader) |
~13t |
【转销形式】 Twist lock Mode |
ISO浮动转销，油缸驱动 ISO floating twist lock, driven by an oil cylinder |
|
伸缩(20’到45’) Expansion time (20’to 45’) |
~ 30 S |
【伸缩驱动方式】 Telescopic Mode |
液 压 马 达 驱 动 链 轮 /滚 子 链 传 动 The telescopic system is driven by means of a hydraulic motor and reduction gearbox connected to an endless chain. |
|
转销( 90°) Twist lock rotation 90° |
~ 1 S |
||
|
导板(180°) Flipper through 180° |
5~7S |
【导板装置】 Flippers Device |
液压驱动 The flippers are drived by hydraulic |
|
电源电压/频率 Power voltage/ Frequency |
AC 380V (3P)/50HZ (可选/ as agreed) |
【适用】 Application |
门座式起重机,臂架起重机,岸桥,轨道吊,轮胎吊 Portal crane, Jib crane, QC, RMG, RTG |
|
操作方式 Operating mode |
驾操 Driving operation |
电气控制 Electric control |
西门子/施耐德 SIEMENS / Schneider (可选/ as agreed) |
