技术参数 Technical specifications
|
【型号/Model：DJZX20】 |
控制电压 Control voltage |
AC 220V (可选/ as agreed) |
|
|
适用于操作ISO标准20’集装箱 For operation with ISO standard 20’ container |
总功率 Total power |
＜1KW |
|
|
额定起重量 Rated lifting load |
41T |
防护等级 Precaution class |
IP 55 |
|
允许载荷偏心 Allowable load eccentricity |
±10% |
导板类型 Flippers Model |
固定导板 Fixed Flipper |
|
四角吊耳负重 Load of lifting lugs at four corner |
12.5t×4 |
环境温度 Ambient temperature |
-20℃~+55℃ |
|
自重(吊具部分) Self-weight (spreader) |
3.5t |
转销形式 Twist lock Mode |
ISO浮动转销，电机驱动 ISO floating twist lock, driven by an motor |
|
转销( 90°) Twist lock rotation 90° |
~ 1 S |
适用 Application |
岸桥，轨道吊，轮胎吊，门座式起重机 QC, RMG, RTG, Portal crane |
|
电源电压/频率 Power voltage/ Frequency |
AC 380V (3P)/50HZ (可选/ as agreed) |
||
